Furnish New Battery Exide Battery Classic OPzS 2V 24OPzS 3000LA FM8
Technology: Pb_VLA_Flooded_gt.pngFurnish New Battery Exide Battery Classic OPzS 2V 24OPzS 3000LA FM8
$2,870.40
Material Value Cost Due from Customer.
Furnish New Battery Exide Battery Classic OPzS 2V 24OPzS 3000LA FM8
| Battery Model | Exide Battery Classic OPzS 2V 24OPzS 3000LA FM8 |
|---|---|
| Adjustment | 1 |
| AH Per String | 3588.52 |
| AH Per String Rating | 8 hr @ 1.75 VPC |
| Cells Per Unit | 1 |
| Nominal VPC | 2 |
| Model KWH | 7 |
| Charge VPC | 2.4 (Min: 2.37, Max: 2.4) |
| Discharge VPC | Min: 1.6, Max: 1.9 |
| Operational Temp Comp | -0.003 V/°C/cell |
| Cycle Temp Comp | -0.004 V/°C/cell |
| Discharge Temp Range | -20°C to 55°C |
| Charge Temp Range | -20°C to 55°C |
| ISC Amps | 18600 |
| Internal Resistance | 0.00011 Ohms |
| Dimensions (L x W x H) | 8.8582725 x 22.834658 x 31.9685212 in |
| Weight | 478.40254 lbs |
| Number of Posts | 4 |
| Terminal Bolt Diameter | 0.315 in (F8 mm) |
| Torque (Initial / Maintenance) | 133 / 133 in-lbs |
| Container | V0 |
| Terminal | F8 |
| FOB | T |
| Max Continuous Discharge | 3229.256 Amps |
| Max Charge Amps | 968.7768 Amps |
| Max In Series / Parallel | 0 / 0 |
| Watts Per Cell (15min 1.67) | 4188 |
| Watts Per Cell Rating | 15 min @ 1.67 VPC |
| Weight of Electrolyte | 95.680508 lbs |
