Furnish New Battery Enersys Data Safe HX 12HX400 D 0 236

Technology: Lead_Acid_Over120lbs
Furnish New Battery Enersys Data Safe HX 12HX400 D 0 236

$302.69

Description
Reference Documents
Battery Model
Specifications
Racks

Download Technical Data Sheet

Download Product Safety Data Sheet

Download Marketing Flyer

Download Product Install/Operations Manual

Battery Model	Enersys Data Safe HX 12HX400 D 0 236
Adjustment	1
AH Per String	67.67
AH Per String Rating	8 hr @ 1.75 VPC
Cells Per Unit	6
Nominal VPC	2
Model KWH	1
Charge VPC	2.4 (Min: 2.37, Max: 2.4)
Discharge VPC	Min: 1.6, Max: 1.9
Operational Temp Comp	-0.003 V/°C/cell
Cycle Temp Comp	-0.004 V/°C/cell
Discharge Temp Range	-20°C to 50°C
Charge Temp Range	-20°C to 50°C
ISC Amps	4359
Internal Resistance	0.0011 Ohms
Dimensions (L x W x H)	13.307 x 6.811 x 8.307 in
Weight	80.03 lbs
Number of Posts	1
Terminal Bolt Diameter	0.236 in (Copp mm)
Torque (Initial / Maintenance)	90 / 95 in-lbs
Container	V0
Terminal	Copper_Insert
FOB	T
Max Continuous Discharge	203.01 Amps
Max Charge Amps	20.301 Amps
Max In Series / Parallel	0 / 0
Watts Per Cell (15min 1.67)	381
Watts Per Cell Rating	15 min @ 1.67 VPC
Weight of Electrolyte	2.985002206 lbs

Part Number	Description	Dimensions (L x W x H)	Max Capacity
